Check Configuration and Wiring

To use NcStudio V10 glass cutting CNC system, checking configuration and wiring is required.

Prerequisites

In bus type configuration mode, please check the hardware configuration as following list:

  • Lambda 5M controller
  • Servo drives
  • Servo motors
  • PM95A control card
  • Host computer (with PCIE slot)
  • EX31A terminal board
  • Optional: handwheel

In non-bus type configuration mode, please check the hardware configuration as following list:

  • Lambda 3S/3L/4S/5S/5E controller
  • Servo drives
  • Servo motors
  • PM95A control card
  • Host computer (with PCIE slot)
  • EX27A/EX31A terminal board (For Lambda 3L controller, a terminal board is not required.)
  • Optional: handwheel

Lambda 3S/4S controller matches EX27A terminal board, and Lambda 5S/5E controller matches EX31A terminal board.

Steps

To check configuration and wiring, do the following:

  1. Confirm space for installation
  2. Install control card
  3. Hardware wiring
  4. Wiring of I/O port

Confirm Space for Installation

To install the hardware device, please check the specification of the product and ensure that there is sufficient space for installation.

Please refer to Related Dimensional Drawing for details.

Install Control Card

To install control card, do the following:

  1. Turn off the power supply of host computer, and open the case.

  2. Insert the motion control card into PCIE slot.

  3. Tighten the mounting screw, and close the case.

  4. Restart the computer.

Hardware Wiring

This part introduces hardware wiring in bus type and non-bus type configurations.

Taking PM95A control card as an example, connect as follows:

In bus type configuration:

In non-bus type configuration:

Wiring of I/O Port

This part introduces wiring of I/O port in bus type and non-bus type configurations.

Connect the product as follows:

In bus type configuration:

  • Wiring diagram of I/O port of Lambda 5M controller is as follows:

  • Wiring diagram of I/O port of EX31A terminal board is as follows:

In non-bus type configuration:

  • Wiring diagram of I/O port of Lambda 4S controller is as follows:

  • Wiring diagram of I/O port of EX27A terminal board is as follows:

  • Wiring diagram of I/O port of Lambda 3L controller is as follows:
